Cross border
High frequency inverter control machine (sine wave) HPS
Power: 3000VA/2400W Output voltage: 220VAC/50/60HZ Battery voltage: 24VDC
Charging current: 20A/30A PWM controller 50A
Mains mode priority/Solar mode priority adjustable
Cross-border exclusive: Amazon, AliExpress, eBay, International Station, LAZADA
Large quantity is preferred, if you need to order large quantities of customers can contact online customer service Huang 24 hours a day online can send mobile phone SMS message
Note: The correct system battery capacity is determined according to the specific needs of the load and application scenarios, otherwise it is easy to lead to insufficient battery capacity or excessive waste of power generation. For details, please refer to the manual recommendation or consult online customer service.
Product Specifications:
| Model number |
HPS-3K |
| Rated power |
3KVA 2400W |
| input |
| voltage |
230VAC |
| Selectable voltage range |
170-280 VAC (personal computer); 90-280 VAC (Home Appliances) |
| Frequency range |
50 Hz/60 Hz(adaptive) |
| exportation |
| Instantaneous maximum power |
6000VA |
|
| AC Voltage regulation (Batt.Mode) |
230VAC ± 5% |
| Output voltage waveform |
Pure sine wave |
| Efficiency (peak) |
93% |
| Switching time |
10ms (Personal computers) 20ms(Home appliances) |
| Battery &AC charging |
| Battery voltage |
24VDC |
| Floating charge voltage |
27VDC |
| Overcharge protection voltage |
31VDC |
| MPPT solar charger |
| Maximum photovoltaic array power |
1200W |
| Charging current |
50A |
| Maximum AC charging current |
20/30A |
| Maximum charging current (AC+ solar charging) |
80A |
| Charging mode |
PWM |
| Maximum photovoltaic panel power |
5000W |
6000W |
| Operating voltage range |
30~80Vdc |
| Maximum open circuit voltage of photovoltaic array |
80Vdc |
| Packaging information |
| Dimensions (L * W * H),mm. |
305 * 272 * 100 |
| Net weight (KG) |
5.2 |
| Gross weight (KG) |
6.5 |
| Safety certification |
CE |
| Communication interface |
RS485 |
| Operating environment |
| humidness |
5% ~ 95% relative humidity (non-condensing) |
|
| Operating temperature |
0°C~55°C |
|
| Storage temperature |
-15°C~60°C |
|
Note: This product has been cancelled disc, not standard
| |
| Wholesale contact customer service quote |
| |
